Vertex

Vertex Two Tier Floating Pond Fountain

Vertex Two Tier Floating Pond Fountain

$10,000.00 USD
$10,000.00 USD
Sale Sold out
Shipping calculated at checkout.

Two-Tier Floating Pond Fountain

The Two-Tier floating pond fountain creates a striking water display with its large spray pattern. Precision brass nozzles produce powerful, arcing side jets, making a dramatic visual impact day or night, especially with optional lighting. Expect reliable, high-quality operation from a Two-Tier pond fountain, built with a UL-certified control box and a durable submersible pump. All components are fully waterproof and constructed from premium, corrosion-resistant materials.

Vertex TwoTier Floating Pond Fountain

Features & Benefits

Nozzles

  • Precision-machined brass/bronze or stainless steel nozzles

Pumps / Motors

  • Efficient turbine pump/motor assembly
  • Constructed from stainless steel
  • Water-cooled: no oil, seals, or o-rings required
  • 4-year warranty

Flotation

  • Rotomolded polypropylene with UV protection for durability
  • Separate leveling sections for precise setup
  • 4-year warranty

Control Panel

  • UL listed in accordance with National Electrical Code
  • Weather-resistant steel enclosures

Submersible Light Fixtures

  • Energy-efficient LED, 140 lumens/watt
  • Stainless steel housing
  • 2-year warranty

Cables

  • STW-A rated
  • 4-year warranty

Technical Specifications

Vertex TwoTier Floating Pond Fountain Spray Specifications


 2 HP Unit
 3 HP Unit 5 HP Unit 7.5 HP Unit 10 HP Unit 15 HP Unit
Minimum Operating Depth 3' 4' 4'
 5' 6' 7'
Center Height (A) 18' 23'
 26' 30′ 35′ 40'
Side Height (B) 8' 10' 12' 15' 17' 20'
Diameter (C) 20′ 25′ 30′ 35' 40′ 45′
LED Lights 2 2 3 4 4 5
Total Wattage 86W 86W 129W 172W 172W 215W
AMP Draw 1 1 1.5 2 2 2.5
Available Phase 1 & 3 1 & 3 1 & 3 1 & 3 1 & 3 1 & 3
1 Phase (Volts) 230 230 230 230 230 230
3 Phase (Volts) 208 or 230 208 or 230 208 or 230 208 or 230 208 or 230 208 or 230
Display Heads Warranty 4-Year
 4-Year 4-Year 4-Year 4-Year 4-Year
Pumps & Motors Warranty 4-Year 4-Year 4-Year 4-Year 4-Year 4-Year
LED Lighting Warranty 2-year 2-year 2-year 2-year 2-year 2-year
Control Panel Warranty 1-Year 1-Year 1-Year 1-Year 1-Year 1-Year
